automatic stencil cutting        CUTTING & PRINTING




We recommend a computerised stencil machine if you need more than one size characters or confronted with rigid specifications.
The computerised stencil machine can cut stencils that range from 1/8" to 24" text, which provides more flexibility.
The machine allows the operator to create standard character and graphic design stencils directly on a PC which is then sent directly to the stencil cutting machine.
The user can design, recall and cut almost any type or size of stencil or sign, right from the keyboard, with speed and simplicity.  Stretch, compress, enlarge, reduce, move, slant, size, rotate, duplicate, mirror, delete, undo, redo, cut, copy, and paste comments on screen.

The machine accepts external files created in other software like Adobe Illustrator and CAD programs allowing for some fairly intricate stencil pattern creation and production.  A computer that has Windows XP, Vista, 7 or 8.1 software is required.
A system consists of stencil & decal cutter, cables, 2 blades and software.

The stencil cutting machine can be used in many industries such as Aerospace, Crating, Automotive, Precast, Manufacturing, Steel, Pipe, Welding, Army, Navy, Airforce, Marines and etc.



COMPUTERISED STENCIL MACHINE FEATURES:

- Heavy duty cutting bed. Will cut vinyl, sandblast, magnetic and polyethylene stencil & decal materials
- Can use up to 28" wide cutting material. Most material comes in rolls and mounts on the machine cradle for easy
- unwind during the cutting process.
- Knife force up to 400 grams. This allows the system to cut heavy materials like magnetic and sandblast.
- Digital servo drive
- Repeat function and easy to use keypad
- Test cut feature
- Easily replaceable blades



STENCIL SOFTWARE FEATURES:
This software is made by Symbol Graphics. SGI has been a leader in the industry for many years.
They produce a software package that is easy to understand.  The user can cut multiple line & size stencils in minutes.

- Multiple Line Cutting
- Left, Center or Right Justification
- Space Adjustment Between Characters
- Manipulation of Character Height & Width
- Cutting Stencil in an Arc Format
- Rotating Text (Cutter Cuts in any Direction)
- Saving & Naming Stencil Files
- Many Stencil & Decal (Vinyl) Fonts to Choose From



STENCIL MATERIALS


POLYETHYLENE STENCILS
- A strong .008" thick polyethylene with low tack reusable adhesive
- Extremely durable
- Allows stencil to stick briefly to the item to be stenciled. no tape or magnets
- Great for marking pipe or hard to mark surfaces

OILBOARD STENCILS
- 0.015" Thick oil treated tagboard
- Can be used many, many times

MYLAR STENCILS (Milky Plastic)
- 0.005" - .014" Thick plastic material
- Extremely durable
- Can be cleaned with solvent & used over and  over again

MAGNETIC STENCILS
- 0.015" Thick magnetic stencil
- Marks drums, pipes, steel, railcars etc.

ABS PLASTIC STENCILS
- A material heavy enough to be used on a parking lot or warehouse floor


WE HAVE 50 STENCIL FONTS IN OUR STENCIL-ART SOFTWARE (Partial List)
